2021-05-05 (W) Wearable Macro Keyboard BackOfTheHand BotH Revised Mount Sketch

I was unhappy with my infrared sensor mount design. It felt slapped together and unreliable. On top of everything, I didn't think the LED aiming was going to work. I learned from what I didn't like and designed a taller one, put the IR emitters directly over the fingers, and pointed down instead of out.

I sketched the piece as three parts. The first part is the mount, where it attaches to the platform. The second is an aerial that can hold the receiver. The final portion is a couple of sockets for the LEDs.



Design sketch
